Orange Pi 3 LTS is an open-source single-board computer with dual-band wireless WiFi and Bluetooth 5.0 .It is highly compact with a dimension of 56X85mm.

Orange Pi 3 LTS is for anyone who wants to start creating with technology- not just consuming it. lt's a simple, fun, useful tool that you can use to start taking control of the world around you.

Hardware Specification:

CPU:
Allwinner H6
Quad-core 64-bit 1.8GHz high-performance Cortex-A53 processor
GPU:
• High-performance multi-core GPU Mali T720
• OpenGL ES3.1/3.0/2.0/1.1
• Microsoft DirectX 11 FL9_3
• ASTC(Adaptive Scalable Texture Compression)
• Floating point operation greater than 70 GFLOPS
Power management chip: AXP805
RAM: 2GB LPDDR3 (shared with GPU)
Onboard Storage:
• Micro SD card slot
• 8GB EMMC Flash
Onboard Network:
• YT8531C Chip
• Support 10/100M/1000M Ethernet
Onboard WiFi+Bluetooth:
• 859 Chip
• Support IEEE 802.11 a/b/g/n/ac
• Support BT5.0
Video Output:
• HDMI 2.0a
• TV CVBS Output
Audio output:
• HDMI Output
• 3.5mm Audio Port
Power Source: 5V3A Type-C
USB: 1* USB 3.0 HOST、2* USB 2.0 HOST
Low-level peripherals: 26pin connector with1* I2C, 1*SPI, 1*UART &Multiple GPIO Ports
Debug serial port: UART-TX、UART-RX & GND
Button: Power Button (SW4)
LED: Power LED& Status LED
IR Receiver: Support IR Remote Control
Supported OS: Android 9.0、Ubuntu、Debian
Dimension: 56mm*85mm
Weight: 45g
